Comparison Of Programing Language

Here are the release dates of the following programming languages:

• C: C was first released on March 8, 1972.

• Objective-C: Objective-C was first released on 1984.

• C++: C++ was first released in 1985.

• Python: Python was first released on February 20, 1991.

• Java: Java was first released on May 23, 1995.

• PHP: PHP was first released on June 8, 1995.

• JavaScript: PHP was first released on December 4, 1995.

In Flutter, the layout principle of “Constraints go down, Sizes go up, Parent sets position” is a clear and distinct mechanism for handling the layout of widgets. When comparing this with the layout mechanisms in Android, iOS, and HTML5/CSS/JS, we find different approaches and philosophies. Let’s compare these systems to understand their similarities and differences.

Layout and Size in Different Systems

Flutter

• Constraints Go Down: Parent widgets send constraints to their children, specifying permissible sizes.
• Sizes Go Up: Children choose their size within those constraints.
• Parent Sets Position: Parents position children based on their size and constraints.

Android (View System)

• Measure Phase:
  • Parent Determines Constraints: Parent views provide measurement specifications (MeasureSpec) to children.
  • Children Measure Size: Children determine their desired size based on these specifications, including modes (EXACTLY, AT_MOST, UNSPECIFIED).
• Layout Phase:
  • Parent Sets Size and Position: Parents decide the final size and position of each child view using the layout() method, setting exact bounds within the parent’s coordinate system.

iOS (UIKit)

• Constraints (Auto Layout):
  • Constraints Propagation: Constraints define relationships between views, such as size ratios or alignments.
  • Size Determination: Each view calculates its size based on these constraints and intrinsic content size.
• Layout Passes:
  • Parent Resolves Constraints: Constraints are resolved to compute the frames (positions and sizes) of views.
  • Frames Set Position: The final position and size of each view are determined by resolving the constraints to specific frames.

HTML5/CSS/JS

• CSS Box Model:
  • Constraints Through CSS: CSS rules (like width, height, max-width, min-width, etc.) define size constraints.
  • Size Computation: Elements calculate their size based on CSS rules, content size, and parent constraints.
• Layout Mechanisms:
  • Flow Layout: Default document flow where elements take up available space in order.
  • Flexbox: Parent container defines constraints and alignment for flex items, which then size themselves within these constraints.
  • Grid Layout: Parent defines a grid structure, and child elements size and position themselves within grid areas.
• Positioning:
  • CSS Positioning: Elements can be positioned using properties like position, top, left, right, and bottom, relative to their parent or document flow.

Comparison: Key Aspects

Constraints Handling

• Flutter: Constraints explicitly passed from parent to child in a hierarchical manner.
• Android: Constraints come from measure specs which include modes and sizes, less explicit than Flutter.
• iOS: Constraints are set using Auto Layout, forming a constraint system that is resolved for size and position.
• HTML/CSS: Constraints defined using CSS properties; more flexible and varied ways to specify constraints.

Size Determination

• Flutter: Children determine size within provided constraints.
• Android: Children measure themselves based on measure specs and report back desired sizes.
• iOS: Size determined by solving constraints in Auto Layout system.
• HTML/CSS: Size determined by CSS rules, intrinsic content, and parent constraints.

Positioning

• Flutter: Parent sets position of children after size determination.
• Android: Parent uses layout() method to set position within bounds.
• iOS: Position determined by resolving constraints to frames.
• HTML/CSS: Position determined by CSS properties and layout rules (flow, flexbox, grid).

Flexibility

• Flutter: Clear and flexible constraint-based system.
• Android: More rigid with fixed measure/layout phases.
• iOS: Flexible but complex due to constraint-solving.
• HTML/CSS: Highly flexible with multiple layout models (flow, flexbox, grid).

Examples

Flutter Example:

Container(
  constraints: BoxConstraints(
    minWidth: 100,
    maxWidth: 200,
  ),
  child: Text('Hello'),
)

• Constraints: Container sends constraints to Text.
• Size: Text chooses a size within constraints.
• Position: Container sets the position of Text.

Android Example:

<LinearLayout
    android:layout_width="match_parent"
    android:layout_height="match_parent">
    <TextView
        android:layout_width="wrap_content"
        android:layout_height="wrap_content"
        android:text="Hello"/>
</LinearLayout>

• Constraints: LinearLayout provides measure specs to TextView.
• Size: TextView measures itself based on specs.
• Position: LinearLayout sets TextView’s position using layout().

iOS Example:

let container = UIView()
container.translatesAutoresizingMaskIntoConstraints = false

let label = UILabel()
label.translatesAutoresizingMaskIntoConstraints = false
label.text = "Hello"

container.addSubview(label)
NSLayoutConstraint.activate([
    label.widthAnchor.constraint(greaterThanOrEqualToConstant: 100),
    label.widthAnchor.constraint(lessThanOrEqualToConstant: 200),
    label.centerXAnchor.constraint(equalTo: container.centerXAnchor),
    label.centerYAnchor.constraint(equalTo: container.centerYAnchor)
])

• Constraints: NSLayoutConstraint sets constraints on label.
• Size: UILabel sizes itself based on constraints.
• Position: Constraints determine UILabel’s position within container.

HTML/CSS Example:

<div style="display: flex; justify-content: center; align-items: center; width: 200px; height: 200px;">
  <div style="min-width: 100px; max-width: 200px;">
    Hello
  </div>
</div>

• Constraints: CSS properties define constraints.
• Size: Child div sizes itself based on min and max width.
• Position: Parent div positions the child using flexbox.

Summary

The layout systems in Flutter, Android, iOS, and HTML5/CSS/JS each have their own approaches:

Must-know information about Swift

entry point

main?

print log

print("Hello swift")
let name = "swift"
print("Hello, \(name)")
print("Hello, \(name1 ?? name)")// If the optional value is missing, the default value is used instead.

Variable, Constant

Int:

• On a 32-bit platform, Int is the same size as Int32.
• On a 64-bit platform, Int is the same size as Int64.

UInt:

• On a 32-bit platform, UInt is the same size as UInt32.
• On a 64-bit platform, UInt is the same size as UInt64.

Double represents a 64-bit floating-point number.

The Flutter Plugin Project Files

Creating the plugin project

$ flutter create --org com.example --template=plugin --platforms=android,ios,linux,macos,windows hello_plugin

Signing iOS app for device deployment using developer identity: "Apple
Development: Yaohong Huang (WS3UUERGF9)"
Creating project hello_plugin...
Resolving dependencies in hello_plugin... (3.3s)
Got dependencies in hello_plugin.
Resolving dependencies in hello_plugin/example... (1.1s)
Got dependencies in hello_plugin/example.
Wrote 161 files.

All done!

Your plugin code is in hello_plugin/lib/hello_plugin.dart.

Your example app code is in hello_plugin/example/lib/main.dart.


Host platform code is in the android, ios, linux, macos, windows directories
under hello_plugin.
To edit platform code in an IDE see
https://flutter.dev/developing-packages/#edit-plugin-package.


To add platforms, run `flutter create -t plugin --platforms <platforms> .` under
hello_plugin.
For more information, see https://flutter.dev/go/plugin-platforms.

hello_plugin
├── CHANGELOG.md
├── LICENSE
├── README.md
├── analysis_options.yaml
├── android
│   ├── build.gradle
│   ├── hello_plugin_android.iml
│   ├── local.properties
│   ├── settings.gradle
│   └── src
│       ├── main
│       └── test
├── example
│   ├── README.md
│   ├── analysis_options.yaml
│   ├── android
│   │   ├── app
│   │   ├── build.gradle
│   │   ├── gradle
│   │   ├── gradle.properties
│   │   ├── gradlew
│   │   ├── gradlew.bat
│   │   ├── hello_plugin_example_android.iml
│   │   ├── local.properties
│   │   └── settings.gradle
│   ├── build
│   │   ├── 52f352800ae67b257006addf8ca3668f
│   │   ├── e29aedf18e567df5728f6b7ce57d2e97.cache.dill.track.dill
│   │   ├── ios
│   │   └── last_build_run.json
│   ├── hello_plugin_example.iml
│   ├── integration_test
│   │   └── plugin_integration_test.dart
│   ├── ios
│   │   ├── Flutter
│   │   ├── Podfile
│   │   ├── Podfile.lock
│   │   ├── Pods
│   │   ├── Runner
│   │   ├── Runner.xcodeproj
│   │   ├── Runner.xcworkspace
│   │   └── RunnerTests
│   ├── lib
│   │   └── main.dart
│   ├── linux
│   │   ├── CMakeLists.txt
│   │   ├── flutter
│   │   ├── main.cc
│   │   ├── my_application.cc
│   │   └── my_application.h
│   ├── macos
│   │   ├── Flutter
│   │   ├── Podfile
│   │   ├── Runner
│   │   ├── Runner.xcodeproj
│   │   ├── Runner.xcworkspace
│   │   └── RunnerTests
│   ├── pubspec.lock
│   ├── pubspec.yaml
│   ├── test
│   │   └── widget_test.dart
│   └── windows
│       ├── CMakeLists.txt
│       ├── flutter
│       └── runner
├── hello_plugin.iml
├── ios
│   ├── Assets
│   ├── Classes
│   │   └── HelloPlugin.swift
│   └── hello_plugin.podspec
├── lib
│   ├── hello_plugin.dart
│   ├── hello_plugin_method_channel.dart
│   └── hello_plugin_platform_interface.dart
├── linux
│   ├── CMakeLists.txt
│   ├── hello_plugin.cc
│   ├── hello_plugin_private.h
│   ├── include
│   │   └── hello_plugin
│   └── test
│       └── hello_plugin_test.cc
├── macos
│   ├── Classes
│   │   └── HelloPlugin.swift
│   └── hello_plugin.podspec
├── pubspec.lock
├── pubspec.yaml
├── test
│   ├── hello_plugin_method_channel_test.dart
│   └── hello_plugin_test.dart
└── windows
    ├── CMakeLists.txt
    ├── hello_plugin.cpp
    ├── hello_plugin.h
    ├── hello_plugin_c_api.cpp
    ├── include
    │   └── hello_plugin
    └── test
        └── hello_plugin_test.cpp

name: hello_plugin
description: A new Flutter plugin project.
version: 0.0.1
homepage:

environment:
  sdk: '>=3.0.5 <4.0.0'
  flutter: ">=3.3.0"

dependencies:
  flutter:
    sdk: flutter
  plugin_platform_interface: ^2.0.2

dev_dependencies:
  flutter_test:
    sdk: flutter
  flutter_lints: ^2.0.0

# For information on the generic Dart part of this file, see the
# following page: https://dart.dev/tools/pub/pubspec

# The following section is specific to Flutter packages.
flutter:
  # This section identifies this Flutter project as a plugin project.
  # The 'pluginClass' specifies the class (in Java, Kotlin, Swift, Objective-C, etc.)
  # which should be registered in the plugin registry. This is required for
  # using method channels.
  # The Android 'package' specifies package in which the registered class is.
  # This is required for using method channels on Android.
  # The 'ffiPlugin' specifies that native code should be built and bundled.
  # This is required for using `dart:ffi`.
  # All these are used by the tooling to maintain consistency when
  # adding or updating assets for this project.
  plugin:
    platforms:
      android:
        package: com.example.hello_plugin
        pluginClass: HelloPlugin
      ios:
        pluginClass: HelloPlugin
      linux:
        pluginClass: HelloPlugin
      macos:
        pluginClass: HelloPlugin
      windows:
        pluginClass: HelloPluginCApi

The method with the same name from the last mixin will override the previous ones in dart

TestMixin file:

class MyObject{
    init(){
        print("draw object");
    }
}

mixin Circle{

    init(){
        print("draw circle");
    }
}


mixin Square{
    init(){
        print("draw Square");
    }
}

class MyShape extends MyObject with Circle, Square{
    init() {
        super.init();
        print("draw MyShape");
    }
}


void main() {
    MyShape shape = MyShape();
    shape.init();
}

//Output:

draw Square
draw MyShape

Rhythmically Intermittent When my Iphone 12 Connect To MacOS

Recently, when my iPhone connects to MacOS, the battery icon on the phone alternates between showing the charging (lightning bolt icon) for a few seconds and then disappearing (no charging battery icon). This continuous loop prevents the phone from charging through MacOS and also hinders the ability to debug iPhone apps.

Mac system version with the issue: macOS Monterey Version 12.7.3 iPhone version with the issue: iOS 16.1

Xcode or Android Studio is unable to list my iPhone device

I encountered an issue where my iPhone12 device was not listed in Android Studio while I was developing.

The issue was dispeared after I restart my macOS, but it occurred again when I reopened my MacBook Pro from sleep mode.

I noticed a new process running in Activity Monitor during the issue occurred.

Here is the process list while android Studio is able to detect my iPhone device:
